Super Mute Slow Moving Large Industrial . For Amusement Park

Name: Super Mute Slow Moving Large Industrial . For Amusement Park
Brand: Bigfans (Wuhan) ventilation equipment Co. Ltd
SKU: SFFCA73
Availability: InStock

Brand Name:	BIGFANS
Model Number:	SFFCA73
MOQ:	10 Sets
Price:	Can Be Negotiable
Payment Terms:	T/T,L/C
Supply Ability:	1000 Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Wuhan

Certification:

CE&ISO

Motor Type:

PMSM (Permanent Magnet Synchronous Motor)

Size:

24FT Diameters

Motor Power:

1.5KW

Control Options:

Remote Control

Noise Level:

40dB

Blade Materia:

Aviation Magnesium-Aluminum Alloy Material

Blades Thinkness:

2mm

Type:

Ceiling Mounted

Power Supply:

Single/Three-phase 220V/380V

Packaging Details:

Wooden Box

Supply Ability:

1000 Per Month

Highlight:

Super Mute Large Industrial Ceiling Fans

Slow Moving Large Industrial Ceiling Fans

Amusement Park Large

Product Description

Super Mute Slow-Moving Large Fans Industrial Ceiling Fans For Large Amusement Park

Product Description:

Gearless PMSM HVLS (High Volume, Low Speed) fans are a type of high-efficiency, energy-saving, and low-noise ventilation equipment primarily used for cooling and ventilation in large spaces such as warehouses, factories, sports arenas, and large commercial venues.

It can promote the circulation of airflow in the space with higher efficiency, achieve the purpose of cooling down the personnel, and improve the comfort of the environment.

Features:

1. High Torque Density

2. Wider blades

3. Higher air volume

4. Precise Speed Control

5. Durability & Safety

Technical Parameters:

DIAMETER	8ft(2.5m)	12ft(3.8m)	16ft(5.0m)	20ft(6.2m)	24ft(7.3m)
MODEL	SFFCA25	SFFCA38	SFFCA50	SFFCA62	SFFCA73
AIR VOLUME	6500m³/min	8600m³/min	13050m³/min	14100m³/min	15850m³/min
MAXIMUM SPEED	140RPM	100RPM	70RPM	60RPM	55RPM
WEIGHT	35Kg	51Kg	75Kg	90Kg	127Kg
MOTOR POWER	0.3kw	0.4kw	1.1kw	1.1kw	1.5kw
FULL LOAD CURRENT	1.8AMPS/220V	2.0Amps/380v 2.3Amps/220v	2.4Amps/380v 3.2Amps/220v	3.0Amps/380v 3.5Amps/220v	3.5Amps/380v 5.5Amps/220v

Basic technical parameters: Model SFFCA73 (PMSM SERIES)

Super Mute Slow Moving Large Industrial . For Amusement Park 0

Applications:

✔ Manufacturing
✔ Industrial Plants
✔ Warehousing & Logistics

✔ School

✔ Garage

✔ Construction & Mining

✔ Traffic Hub

✔ Commercial Places

Super Mute Slow Moving Large Industrial . For Amusement Park 1

Support and Services:

The Product Technical Support and Services for the PMSM Series HVLS Industrial Fans include:

- Maintenance recommendations to keep the fan running efficiently and prolong its lifespan.

- Warranty support to address any defects or malfunctions covered under the product warranty.

Super Mute Slow Moving Large Industrial . For Amusement Park 2

Packing and Shipping:

Each fan is securely wrapped and placed in a sturdy wooden box with ample cushioning material to prevent any damage during transit, and a set of big fans is composed of a square box and a long box.

Super Mute Slow Moving Large Industrial . For Amusement Park 3

FAQ:

Q: Are you factory or trading company?
A: We are factory which established more than 12 years.

Q: How is your motor’s quality compared with others?
A: High efficiency (85%~89%) is our strength.
Low repair rate (less than 0.08%).
All the motors have passed ISO9000, CE.

Q: What is your delivery time?
A: Usually we have stock, delivery time within 7 working days.
If there is customized requirement, time is negotiable.

Q: What other services can you provide?
A: Accepted delivery terms: FOB,CFR,CIF,EXW,DDP,DDU.
Accepted payment type: T/T, L/C;
