HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse

Name: HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse
Brand: Bigfans Ventilation Equipment (Wuhan) Co., Ltd
SKU: SFFCA73
Availability: InStock

Brand Name:	BIGFANS
Model Number:	SFFCA73
MOQ:	10 Sets
Price:	Can Be Negotiable
Payment Terms:	T/T,L/C
Supply Ability:	1000 Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Wuhan

Certification:

CE&ISO

Motor Type:

PMSM (Permanent Magnet Synchronous Motor)

Size:

24FT Diameters

Motor Power:

1.5KW

Control Options:

Remote Control

Noise Level:

40dB

Blade Materia:

Aviation Magnesium-Aluminum Alloy Material

Blades Thinkness:

2mm

Type:

Ceiling Mounted

Power Supply:

Single/Three-phase 220V/380V

Packaging Details:

Wooden Box

Supply Ability:

1000 Per Month

Product Description

HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse

Product Description:

Multiple Sizes Optional: 8FT-24FT (2.5m-7.3m) diameters, customizable for warehouses, factories, farms, gyms, etc.
Energy Saving Up to 80%: Adopts PMSM motor, consumes only 1-3kW/h, significantly reducing electricity costs for large spaces.
Low Operating Cost: High energy efficiency ratio (EER) ensures long-term cost savings, no frequent energy waste compared to traditional fans.
Cost-Effective Cooling Solution: Replaces multiple small fans with one HVLS fan, cutting down initial investment and maintenance expenses.

Features:

1. High Torque Density

2. Wider blades

3. Higher air volume

4. Precise Speed Control

5. Durability & Safety

Technical Parameters:

DIAMETER	8ft(2.5m)	12ft(3.8m)	16ft(5.0m)	20ft(6.2m)	24ft(7.3m)
MODEL	SFFCA25	SFFCA38	SFFCA50	SFFCA62	SFFCA73
AIR VOLUME	6500m³/min	8600m³/min	13050m³/min	14100m³/min	15850m³/min
MAXIMUM SPEED	140RPM	100RPM	70RPM	60RPM	55RPM
WEIGHT	35Kg	51Kg	75Kg	90Kg	127Kg
MOTOR POWER	0.3kw	0.4kw	1.1kw	1.1kw	1.5kw
FULL LOAD CURRENT	1.8AMPS/220V	2.0Amps/380v 2.3Amps/220v	2.4Amps/380v 3.2Amps/220v	3.0Amps/380v 3.5Amps/220v	3.5Amps/380v 5.5Amps/220v

Basic technical parameters: Model SFFCA73 (PMSM SERIES)

HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse 0

Applications:

✔ Manufacturing
✔ Industrial Plants
✔ Warehousing & Logistics

✔ School

✔ Garage

✔ Construction & Mining

✔ Traffic Hub

✔ Commercial Places

HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse 1

Support and Services:

BIGFANS have own installation service team exceeded 100 people, covering the four major regions of South China, East China, Southwest China and Northeast China, providing 24-hour service.

The company's after-sales department adopts an 8-hour response and a 24-hour problem-solving mechanism to serve you wholeheartedly.

HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse 2

Packing and Shipping:

Each fan is securely wrapped and placed in a sturdy wooden box with ample cushioning material to prevent any damage during transit, and a set of big fans is composed of a square box and a long box.

HVLS Industrial Ceiling Fan 24FT/7.3M - AC Motor Energy Saving for Warehouse 3

FAQ:

Q: Are you factory or trading company?
A: We are factory which established more than 12 years.

Q: How is your motor’s quality compared with others?
A: High efficiency (85%~89%) is our strength.
Low repair rate (less than 0.08%).
All the motors have passed ISO9000, CE.

Q: What is your delivery time?
A: Usually we have stock, delivery time within 7 working days.
If there is customized requirement, time is negotiable.

Q: What other services can you provide?
A: Accepted delivery terms: FOB,CFR,CIF,EXW,DDP,DDU.
Accepted payment type: T/T, L/C;
